| Quantity: | |
|---|---|
Xiamen, China
150000pieces/Month
L/C, T/T, D/P, Western Union, Paypal
ZSTWB
Enclosed Type
16/21/27/34/42/53/68 L/Min
15mm/20mm/25mm
Brass/Stainless Steel
Chrome/Natural Brass
0.35MPa
16/21/27/34/42/53/68/86 L/Min
90 Degree to 180 Degree
Open Spray Fire Sprinkler System
SINCO/OEM
Standard Export Carton
1/2"/3/4"/1"
Quanzhou, Fujian
84249090
Upright/Pendent
Open
Deluge Valve
Can′t Automatically Opened and Closed
Deluge System
Dry Fire Sprinkler System
| Model | Flow coefficient(K) | Spraying angle | Connect thread | Type |
| ZSTWB-16-90 | 16 | 90° | R1/2 | Centrifugal (High speed) |
| ZSTWB-16-120 | 16 | 120° | R1/2 | |
| ZSTWB-21-90 | 21 | 90° | R1/2 | |
| ZSTWB-21-120 | 21 | 120° | R1/2 | |
| ZSTWB-27-90 | 27 | 90° | R3/4 | |
| ZSTWB-27-120 | 27 | 120° | R3/4 | |
| ZSTWB-34-90 | 34 | 90° | R3/4 | |
| ZSTWB-34-120 | 34 | 120° | R3/4 | |
| ZSTWB-42-90 | 42 | 90° | R3/4 | |
| ZSTWB-42-120 | 42 | 120° | R3/4 | |
| ZSTWB-53-90 | 53 | 90° | R1 | |
| ZSTWB-53-120 | 53 | 120° | R1 | |
| ZSTWB-68-90 | 68 | 90° | R1 | |
| ZSTWB-68-120 | 68 | 120° | R1 |
| Model specification | Flow coefficient | Spraying angle | Connect thread | Type |
| ZSTWC-63-(90-180) | 34 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-80-(90-180) | 43 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-100-(90-180) | 53 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-160-(90-180) | 86 | 90°-180° | R1/2 or R3/4 | Impact |
| Model | Flow coefficient(K) | Spraying angle | Connect thread | Type |
| ZSTWB-16-90 | 16 | 90° | R1/2 | Centrifugal (High speed) |
| ZSTWB-16-120 | 16 | 120° | R1/2 | |
| ZSTWB-21-90 | 21 | 90° | R1/2 | |
| ZSTWB-21-120 | 21 | 120° | R1/2 | |
| ZSTWB-27-90 | 27 | 90° | R3/4 | |
| ZSTWB-27-120 | 27 | 120° | R3/4 | |
| ZSTWB-34-90 | 34 | 90° | R3/4 | |
| ZSTWB-34-120 | 34 | 120° | R3/4 | |
| ZSTWB-42-90 | 42 | 90° | R3/4 | |
| ZSTWB-42-120 | 42 | 120° | R3/4 | |
| ZSTWB-53-90 | 53 | 90° | R1 | |
| ZSTWB-53-120 | 53 | 120° | R1 | |
| ZSTWB-68-90 | 68 | 90° | R1 | |
| ZSTWB-68-120 | 68 | 120° | R1 |
| Model specification | Flow coefficient | Spraying angle | Connect thread | Type |
| ZSTWC-63-(90-180) | 34 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-80-(90-180) | 43 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-100-(90-180) | 53 | 90°-180° | R1/2 or R3/4 | Impact |
| ZSTWC-160-(90-180) | 86 | 90°-180° | R1/2 or R3/4 | Impact |
