| Quantity: | |
|---|---|
Xiamen, China
200 Sets/Month
L/C, T/T, D/P, Western Union, Paypal, Money Gram
PS/PL
3"(80mm)/4"(100mm)
Water,Foam Mixture
Manual/Electric
SINCO or OEM
Standard Export Package
PS20-PS80/PL24-PL64
Quanzhou, Fujian
8424
Ductile Iron/Aluminum Alloy/Stainless Steel
0.8-1.2MPa
Above 48m~80m
20L/S~80L/S
-70~70 Degree
0~360 Degree
| Model | PS20 | PS30 | PS40 | PS50 | PS60 | PS70 | PS80 |
| L/S | 20 | 30 | 40 | 50 | 60 | 70 | 80 |
| Working Pressure(Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.9 | 0.9 | 0.9 |
| Max Working Pressure(Mpa) | 1.0 | 1.0 | 1.0 | 1.0 | 1.2 | 1.2 | 1.2 |
| Flange Connection(mm) | DN80 | DN80 | DN80 | DN80 | DN100 | DN100 | DN100 |
| Water Jetting Range(m) | ≥ 48 | ≥ 55 | ≥ 60 | ≥ 65 | ≥ 70 | ≥75 | ≥80 |
| Horizontal Angle (Degree) | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 |
| Max Angle Of Elevation (Degree) | 70 | 70 | 70 | 70 | 70 | 70 | 70 |
| Max Angle Of Depression (Degree) | -70 | -70 | -70 | -70 | -70 | -70 | -70 |
| Model | PL24 | PL32 | PL48 | PL64 |
| Flow Range(L/S) | 24 | 32 | 48 | 64 |
| Working Pressure(Mpa) | 1.0 | 1.0 | 1.0 | 1.2 |
| Max Working Pressure(Mpa) | 1.2 | 1.2 | 1.2 | 1.6 |
| Flange Connection(mm) | DN80 | DN80 | DN80 | DN80 |
| Water Jetting Range(m) | ≥ 48 | ≥ 50 | ≥ 60 | ≥ 65 |
| Horizontal Angle (Degree) | 0-360 | 0-360 | 0-360 | 0-360 |
| Max Angle Of Elevation (Degree) | 70 | 70 | 70 | 70 |
| Max Angle Of Depression (Degree) | -70 | -70 | -70 | -70 |
| Model | PS20 | PS30 | PS40 | PS50 | PS60 | PS70 | PS80 |
| L/S | 20 | 30 | 40 | 50 | 60 | 70 | 80 |
| Working Pressure(Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.9 | 0.9 | 0.9 |
| Max Working Pressure(Mpa) | 1.0 | 1.0 | 1.0 | 1.0 | 1.2 | 1.2 | 1.2 |
| Flange Connection(mm) | DN80 | DN80 | DN80 | DN80 | DN100 | DN100 | DN100 |
| Water Jetting Range(m) | ≥ 48 | ≥ 55 | ≥ 60 | ≥ 65 | ≥ 70 | ≥75 | ≥80 |
| Horizontal Angle (Degree) | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 |
| Max Angle Of Elevation (Degree) | 70 | 70 | 70 | 70 | 70 | 70 | 70 |
| Max Angle Of Depression (Degree) | -70 | -70 | -70 | -70 | -70 | -70 | -70 |
| Model | PL24 | PL32 | PL48 | PL64 |
| Flow Range(L/S) | 24 | 32 | 48 | 64 |
| Working Pressure(Mpa) | 1.0 | 1.0 | 1.0 | 1.2 |
| Max Working Pressure(Mpa) | 1.2 | 1.2 | 1.2 | 1.6 |
| Flange Connection(mm) | DN80 | DN80 | DN80 | DN80 |
| Water Jetting Range(m) | ≥ 48 | ≥ 50 | ≥ 60 | ≥ 65 |
| Horizontal Angle (Degree) | 0-360 | 0-360 | 0-360 | 0-360 |
| Max Angle Of Elevation (Degree) | 70 | 70 | 70 | 70 |
| Max Angle Of Depression (Degree) | -70 | -70 | -70 | -70 |
